Hydraulic Elevators
Venux hydraulic elevators are designed for smooth and reliable performance, making them ideal for low to mid-rise buildings. Powered by advanced hydraulic technology, they ensure safe vertical movement with minimal maintenance. Known for their durability and energy efficiency, hydraulic lifts are a cost-effective solution for residential, commercial, and industrial spaces.
Key Features of Hydraulic Lift
Space Efficient – No machine room above the shaft (machine located at the bottom).
Smooth & Quiet Operation – Ideal for low-rise buildings (2–6 floors).
High Load Capacity – Can lift heavy loads (up to 4000 kg or more).
Cost-Effective – Lower installation cost compared to traction lifts.
Customizable – Cabin size, shape, and finishes can be easily tailored.
Safety – Equipped with emergency lowering, overload sensors, and ARD.
Low Civil Work Requirement – Needs a shallow pit and less overhead space.
Energy Saving – Consumes power only during upward travel (downward uses gravity).
Easy Maintenance – Fewer moving parts and longer lifespan.
Application – Widely used in hospitals, residential villas, showrooms, and low-rise commercial buildings.
Technical Specifications of Hydraulic Lift
Load Capacity
Standard range: 320 kg to 4000 kg
Common for passenger lifts: 6–15 persons (450–1000 kg)
Speed
Typically 0.2 m/s – 0.5 m/s
Suitable for low-rise (slow & steady travel).
Travel Height
Max. 12–20 meters (about 4–6 floors).
Power Requirement
3-phase, 380–415 V, 50 Hz (for higher capacity)
Single-phase available for small residential lifts.
Drive System
Hydraulic cylinder with pump unit (direct or indirect).
Uses hydraulic oil pressure to move cabin.
Door Type
Manual swing doors, automatic telescopic, or center-opening doors (optional).
Cabin Dimensions
Customizable – e.g., 1100 × 1400 mm (8 passengers)
Can be made larger for stretcher lifts.
Safety Features
Emergency lowering system (in case of power failure).
Overload sensor, pressure relief valve.
Door interlocks, IR sensors.
Emergency alarm & intercom.
Pit & Headroom
Pit depth: 150–600 mm
Overhead height: 3000–3500 mm
Special Options
Machine room-less type (compact).
Battery-operated emergency lowering.
Energy-efficient pump systems.
Silent operation with noise-reduction technology.
